PRODUCT SHOW

stepper motor

gear stepper motor 20BYJ26

MOQ：Depending on material and product complexity, usually 100PCS

SAMPLE：Available

OEM：We support OEM/ODM

Inquiry

Detail of cooperation

P/N

Application

capacity

Made in

Brand

cert

MOQ

packing

Lead time

20BYJ46

robot

fan

Money detector

80000-10000

pcs/day

China

ROHS

Reach

10pcs

pallet

7-12 days

20BYJ46 Small Motor 35BYJ46 Stepper Motor, Up and Down Sweeping Motor, Air Conditioner Cabinet Motor, Swing Vane Motor, Wind Direction Motor Parts.

The advantage is fast response frequncy ,abrasion resistant and high and low temperature resistance .

specification

Number of phase	4
Step Angel	7.5°/85
Reduction Ratio	1：85
Rated Voltage(phase)	12V (DC)
Resistance (phase)@25℃	150Ω+/-7%
（100pps)/pull in torque	≥49mN.m
cogging torque	≥29.4mN.m
Noise	≤40dB
No load pull in frequency	≥350PPS
No load pull out frequency	≥400PPS
Duty	continuous
Dielectric Strength	AC600V/1S/1mA
(DC 500V)/Insulation Resistance	Above 100MΩ/Min
(UL)/Insulation class	E
Temprature rise	Below 40k/Max
Friction Torque	/
storage Ambient temperature	-5℃-35℃
storage Ambient Humidity	＜75%RH

Drawing of 20BYJ46 motor

Wiring Diagram

Packing

Aplication

Packing warehouse

Make process

Our company can customize all kinds of non-standard products,if necessary.welcome to consult at any time at sales@ksyh-motor.com .
